CBT25/S55M, Turbulent, Ø55mm

Double Bearing Design • Smooth Operation • Extra-long Lifespan

With a fluid mechanics design, the stator has an oblique long hole and the rotor has an impeller. This generates numerous tiny vortices, achieving efficient heat transfer and exchange with minimal shear force and low heat content. It can quickly remove suspended particles in suspended foams or supernatants; it is also suitable for mixing and dissolving medium and high viscosity sample liquids.

INQUIRY

ADD TO CART

Description
Technical Data
Application
Accessories
Videos
Related Products
Inquiry

Description

The stator has oblique long holes and the rotor adopts blade-like design, generating strong turbulence
Low shear force, less heat, achieving efficient vortex-type mixing
Modular design, with a single dispersion shaft, allows for the arbitrary combination of various types of dispersion tools, saving costs
High concentricity, stable and reliable operation, reduced wear of the bushing, and extended service life
Special Polyflon™ PTFE bushings, featuring excellent wear resistance and chemical stability
Optional Sleeve-Alloy™ alloy bushings are available, which are maintenance-free and meet the requirements of high-speed operation
High-precision manufacturing, precise tolerance control, combined with scientific fluid dynamics design, resulting in outstanding material processing performance
Made of sanital-grade stainless steel 316L and treated with electrolytic passivation, it is endowed with excellent corrosion resistance
The inner and outer surfaces have been subjected to physical and electrolytic composite polishing, resulting in high surface finish, easy cleaning and no residue of materials
Multiple types of dispersion tools are available (standard/ sawtooth/ fiber/ emulsified/ turbulent/ dissolved, etc.) to meet the processing requirements of different samples
Multiple diameter dispersion tools are available (Ø25-65mm), with processing capacities ranging from 100ml to 50L
It can withstand chemical sterilization, moist heat sterilization and dry heat sterilization (except rolling bearings)

Technical Data

Model	CBT25/S25M	CBT25/S30M	CBT25/S35M	CBT25/S45M	CBT25/S55M	CBT25/S60M
Cat. No.	292509	293009	293509	294509	295509	296009
Volume Range (H₂O) ml	100-4500	100-8000	100-10000	100-25000	200-35000	500-40000
Stator Diameter mm	Ø25	Ø30	Ø35	Ø45	Ø55	Ø60
Stator Diameter mm	0.25	0.25	0.3	0.3	0.3	0.3
Particle Size of Suspension μm	15-50	15-50	30-80	40-100	40-100	40-100
Emulsion Particle Size μm	5-20	5-20	5-25	10-30	10-30	10-30
Maximum Rotational Speed rpm	25000	25000	25000	25000	25000	25000
Maximum Linear Velocity m/s	22.3	28.8	35.3	48.4	61.5	66.8
Immersion Depth mm	40-235	40-235	40-235	40-235	40-235	40-235
Effective Length mm	270	270	270	270	270	270
Limit Temperature	180℃	180℃	180℃	180℃	180℃	180℃
PH Range	2-13	2-13	2-13	2-13	2-13	2-13
